Product Summary

? Master reset pin with internal pull-up and power-on reset
? IRQ with schmitt-trigger input and programmable pull up
? The MC68HC908JL16 is available in the following packages:
– 28-pin plastic dual in-line package (PDIP)
– 28-pin small outline integrated package (SOIC)
– 32-pin shrink dual in-line package (SDIP)
– 32-pin low-profile quad flat pack (LQFP)
? Specific features in 28-pin packages are:
– 23 general-purpose I/Os only
– 7 keyboard interrupt with internal pull up
– 10 light-emitting diode (LED) drivers (sink)
– 12-channel ADC
– Timer I/O pins on TIM1 only
Features of the CPU08 include the following:
? Enhanced HC05 programming model
? Extensive loop control functions
? 16 addressing modes (eight more than the HC05)
? 16-bit index register and stack pointer
? Memory-to-memory data transfers
? Fast 8 × 8 multiply instruction
? Fast 16/8 divide instruction
? Binary-coded decimal (BCD) instructions
? Optimization for controller applications
? Efficient C language support
