JS28F640J3D75

Embedded Flash Memory, TSSOP56, –2.0 to +5.6 V, 100 mA, low-voltage capability, 64-bit Unique device identifier

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.94~4.56 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	4.56 / Piece
11 ~ 100 :	3.01 / Piece
101 ~ 500 :	1.94 / Piece

PartNumber:: JS28F640J3D75

Brand:: Numonyx B.V - Numonyx | Pack: TSOP | D/C: 10+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Datasheet:: JS28F640J3D75 Datasheet download

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Lucas's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-05

From Other Seller

Part Number:JS28F640J3D75
US $1.94 - 4.56
JS28F640J3D75

US $1.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The JS28F640J3D75 is an Embedded Flash Memory. The device provides improved mainstream performance with enhanced security features, taking advantage of the high quality and reliability of the NOR-based Intel 0.13 μm ETOX VIII process technology. Offered in 128-Mbit (16-Mbyte), 64-Mbit, and 32-Mbit densities, the JS28F640J3D75 brings reliable, low-voltage capability (3 V read, program, and erase) with high speed, low-power operation. The JS28F640J3D75 takes advantage of the proven manufacturing experience and is ideal for code and data applications where high density and low cost are required, such as in networking, telecommunications, digital set top boxes, audio recording, and digital imaging.

Parametrics

JS28F640J3D75 absolute maximum ratings: (1)Temperature under Bias Expanded (TA, Ambient): –40 to +85℃; (2)Storage Temperature: –65 to +125℃; (3)VCC Voltage: –2.0 to +5.6 V; (4)VCCQ: –2.0 to +5.6 V; (5)Voltage on any input/output signal (except VCC, VCCQ): –2.0 to VCCQ (max) + 2.0 V; (6)ISH Output Short Circuit Current: 100 mA.

Features

JS28F640J3D75 features: (1)High-density symmetrical 128-Kbyte blocks; (2)Enhanced security options for code protection; (3)128-bit Protection Register; (4)64-bit Unique device identifier; (5)64-bit User-programmable OTP cells; (6)Absolute protection with VPEN = GND; (7)Individual block locking; (8)Block erase/program lockout during power transitions; (9)75 ns Initial Access Speed (128/64/32 -Mbit densities); (10)95 ns Initial Access Speed (256 Mbit only); (11)25 ns 8-word and 4-word Asynchronous page-mode reads; (12)2-Byte Write buffer; (13)4 μs per Byte Effective programming time; (14)Program and erase suspend support; (15)Flash Data Integrator (FDI), Common Flash Interface (CFI) Compatible.
