MAX3221ECAE

single-channel RS-232 line driver, ssop, -0.3 V to 6 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.73~3.14 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	3.14 / Piece
11 ~ 100 :	1.34 / Piece
101 ~ 500 :	0.73 / Piece

PartNumber:: MAX3221ECAE

Brand:: Maxim Integrated Products - Maxim | Pack: SSOP | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Datasheet:: MAX3221ECAE Datasheet download

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Lucas's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-09

From Other Seller

Part Number:MAX3221ECAE
US $0.73 - 3.14
Quantity:

piece

Product Summary

The MAX3221ECAE is a single-channel RS-232 line driver. It is suitable for battery-powered, hand-held, and portable equipment pdas and palmtop PCs notebooks, subnotebooks, and laptops digital cameras mobile phones and wireless devices.

Parametrics

MAX3221ECAE absolute maximum ratings: (1)Supply voltage range, VCC: -0.3 V to 6 V; (2)Positive output supply voltage range, V+: -0.3 V to 7 V; (3)Negative output supply voltage range, V-: 0.3 V to -7 V; (4)Supply voltage difference, V+ - V-: 13 V; (5)Operating virtual junction temperature, TJ: 150℃; (6)Storage temperature range, Tstg: -65℃ to 150℃.

Features

MAX3221ECAE features: (1)RS-232 Bus-Pin ESD Protection Exceeds ±15 kV Using Human-Body Model (HBM); (2)Meets or Exceeds the Requirements of TIA/EIA-232-F and ITU v.28 Standards; (3)Operates With 3-V to 5.5-V VCC Supply; (4)Operates Up To 250 kbit/s; (5)One Driver and One Receiver; (6)Low Standby Current: 1 μA Typical; (7)External Capacitors: 4 × 0.1 μF; (8)Accepts 5-V Logic Input With 3.3-V Supply; (9)Alternative High-Speed Pin-Compatible; (10)Auto-Powerdown Feature Automatically Disables Drivers for Power Savings.
