Product Summary

The XC2S200-5PQG208C is a member of the Spartan-II 2.5V Field-Programmable Gate Array family giving users high performance, abundant logic resources, and a rich feature set, all at an exceptionally low price. The six-member family offers densities ranging from 15,000 to 200,000 system gates. System performance is supported up to 200 MHz.

Parametrics

Absolute maximum ratings: (1)VCCINT, Supply voltage relative to GND: –0.5 to 3.0 V; (2)VCCO, Supply voltage relative to GND: –0.5 to 4.0 V; (3)VREF, Input reference voltage: –0.5 to 3.6 V; (4)VIN, Input voltage relative to GND:5V tolerant I/O: –0.5 to 5.5 V; No 5V tolerance: –0.5 to VCCO+0.5 V; (5)VTS, Voltage applied to 3-state output: 5V tolerant I/O: –0.5 to 5.5 V; No 5V tolerance: –0.5 to VCCO+0.5 V; (6)TSTG, Storage temperature (ambient): –65 to +150 ℃ ; (7)TJ, Junction temperature: +135 ℃ max.

Features

Features: (1)Second generation ASIC replacement technology; (2)Versatile I/O and packaging: Pb-free package options; Low-cost packages available in all densities; Family footprint compatibility in common packages; 16 high-performance interface standards; Hot swap Compact PCI friendly; Zero hold time simplifies system timing; (3)Fully supported by powerful Xilinx development system: Foundation ISE Series: Fully integrated software; alliance Series: For use with third-party tools; Fully automatic mapping, placement, and routing.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
XC2S200-5PQG208C
XC2S200-5PQG208C


IC SPARTAN-II FPGA 200K 208-PQFP

Data Sheet

0-1: $15.75
