MAX3221EEAE

3V-powered, communications interface, SOP-16, -0.3V to +6V, 571mW, ESD Protection, Small 0.1μF Capacitors

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.73~3.14 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	3.14 / Piece
11 ~ 100 :	1.45 / Piece
101 ~ 500 :	0.73 / Piece

PartNumber:: MAX3221EEAE

Brand:: Maxim Integrated Products - Maxim | Pack: SSOP | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Datasheet:: MAX3221EEAE Datasheet download

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Lucas's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-09

From Other Seller

Part Number:MAX3221EEAE
US $0.73 - 3.14
MAX3221EEAE+

US $1.00 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX3221EEAE is a 3V-powered EIA/TIA-232 and V.28/V.24 communications interface with automatic shutdown/wakeup features, high data-rate capabilities, and enhanced electrostatic discharge (ESD) protection. All transmitter outputs and receiver inputs of the MAX3221EEAE are protected to ±15kV using IEC 1000-4-2 Air-Gap Discharge, to ±8kV using IEC 1000-4-2 Contact Discharge, and to ±15kV using the Human Body Model. The applications of the MAX3221EEAE inlcude Notebook, Subnotebook, and Palmtop Computers, Cellular Phones, Battery-Powered Equipment, Hand-Held Equipment, Peripherals and Printers.

Parametrics

MAX3221EEAE absolute maximum ratings: (1)VCC to GND: -0.3V to +6V; (2)V+ to GND: -0.3V to +7V; (3)V- to GND: +0.3V to -7V; (4)V+ + |V-|: +13V; (5)Input Voltages T_IN, EN, FORCEON, FORCEOFF to GND: -0.3V to +6V; R_IN to GND: ±25V; (6)Output Voltages T_OUT to GND: ±13.2V; R_OUT, R2OUTB, INVALID to GND: -0.3V to (VCC + 0.3V); (7)Short-Circuit Duration T_OUT to GND: Continuous; (8)Continuous Power Dissipation: 571mW; (9)Operating Temperature Ranges: 0 to +70℃; (10)Storage Temperature Range: -65 to +160℃; (11)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX3221EEAE features: (1)ESD Protection for RS-232 I/O Pins: ±15kV—Human Body Model; ±8kV—IEC1000-4-2, Contact Discharge; ±15kV—IEC1000-4-2, Air-Gap Discharge; (2)Latchup Free; (3)1μA Supply Current ; (4)250kbps Guaranteed Data Rate; (5)6V/μs Guaranteed Slew Rate; (6)Meets EIA/TIA-232 Specifications Down to 3.0V; (7)Smallest Single-Supply RS-232 Transceiver; (8)Guaranteed Mouse Driveability; (9)Small 0.1μF Capacitors.
